New

Apocalypse DB-3512R D1/D2

Modifications:
Ω 1+1 Ohm Ω 2+2 Ohm

Series: Apocalypse


Specifications

ModelDB-3512R D1 / DB-3512R D2
TypeSubwoofer
Size12 inch
Voice coil size3.50 inch
ConeCarbon
MagnetFerrite
Voice coil wireNone
SurroundFoam
RMS Power3500 W
MAX Power7000 W
FrameAlu
Impedance1+1 / 2+2 Ohm
SPL86.80 / 86.90 dB
Fs32.50 / 32.80 Hz
Qts0.39 / 0.40
BL24.80 / 26.90
Vas28.90 / 29.60 L
Xmeh45.00 / 45.00 mm
Xmax22.50 / 22.50 mm
Mounting depth9.61 inch (244.0 mm)
Cut-out dimension11.18 inch (284.0 mm)
Gross weight79.26 lb (35.95 kg)
