Series: Apocalypse
Apocalypse DB-315 D1/D2
| Model | DB-315 D1 / DB-315 D2 |
| Type | Subwoofer |
| Size | 15 inch |
| Voice coil size | 3.00 inch |
| Cone | Paper |
| Magnet | Ferrite |
| Voice coil wire | Alu |
| Surround | Foam |
| RMS Power | 3000 W |
| MAX Power | 6000 W |
| Frame | Alu |
| Impedance | 1+1 / 2+2 Ohm |
| SPL | 87.60 / 87.30 dB |
| Fs | 30.00 / 31.00 Hz |
| Qts | 0.51 / 0.56 |
| BL | 18.00 / 25.60 |
| Vas | 60.60 / 58.40 L |
| Xmeh | 50.00 / 50.00 mm |
| Xmax | 25.00 / 25.00 mm |
| Mounting depth | 10.83 inch (275.2 mm) |
| Cut-out dimension | 14.74 inch (374.5 mm) |
| Gross weight | 91.49 lb (41.50 kg) |
