Model | DB-3012R D1 / DB-3012R D2 |
Type | Subwoofer |
Size | 12 inch |
Voice coil size | 3.00 inch |
Cone | Paper |
Magnet | Ferrite |
Voice coil wire | None |
Surround | Foam |
RMS Power | 2800 W |
MAX Power | 5600 W |
Frame | Alu |
Impedance | 1+1 / 2+2 Ohm |
SPL | 86.00 / 86.50 dB |
Fs | 33.00 / 33.80 Hz |
Qts | 0.41 / 0.43 |
BL | 23.80 / 26.00 |
Vas | 29.50 / 30.20 L |
Xmeh | 38.00 / 38.00 mm |
Xmax | 19.00 / 19.00 mm |
Mounting depth | 8.82 inch (224.0 mm) |
Cut-out dimension | 11.18 inch (284.0 mm) |
Gross weight | 61.51 lb (27.90 kg) |
