Series: Machete
The Machete MLA-70.2 XS is a masterclass in efficiency and compact engineering. Designed for those who demand clean, reliable power in a small footprint, this Class D amplifier delivers high-fidelity sound without compromising on space.
Built for versatility, it features simultaneous LPF and HPF operation, allowing you to fine-tune your audio system with professional precision. Whether you are driving high-quality components or a bridgeable subwoofer, the MLA-70.2 XS is your ticket to a refined, punchy sound stage.
| Model | MLA-70.2XS |
| Class | D |
| Number of the channels | 2 |
| Frequency response | 20-20000 Hz |
| 2 Ohm RMS Power (14.4 V) | 100 W x 2 |
| 4 Ohm RMS Power (14.4 V) | 70 W x 2 |
| 4 Ohm RMS Power (Bridge) | 200 W x 1 |
| Minimum permissible load on the channel | 2 Ohm |
| Minimum permissible load in a bridge connection | 4 Ohm |
| Low pass filter | 40-400 Hz |
| High pass filter | 40-400 Hz |
| Crossover | 12 dB/Oct |
| Input terminal | 4 Ga |
| Output terminal | 8 Ga |
| Damping factor | ≥ 180 |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ≥ 85 dB |
| Size (W×L×H) | 5.43 × 3.27 × 1.39 inch |
| Gross weight | 1.46 lb (0.66 kg) |
