Series: Machete
The Machete MFA-5.1000 is the definitive all-in-one solution for audiophiles who refuse to compromise. This high-efficiency Class D amplifier merges four channels of pristine power for your mids and highs with a dedicated, robust subwoofer channel, all housed in a compact, heat-dissipating chassis.
Engineered for versatility, it features advanced 24 dB/oct crossovers and flexible filter settings, allowing you to fine-tune your soundstage with surgical precision. Whether you are building a daily driver or a competitive sound system, the MFA-5.1000 delivers consistent, clean power that brings your music to life.
| Model | MFA-5.1000 |
| Class | D |
| Number of the channels | 5 |
| Frequency response | 10-20000 Hz |
| 2 Ohm RMS Power (14.4 V) | 4 W x 5 |
| 4 Ohm RMS Power (14.4 V) | 4 W x 5 |
| 4 Ohm RMS Power (Bridge) | 2 W |
| Minimum permissible load on the channel | 2 Ohm |
| Minimum permissible load in a bridge connection | 4 Ohm |
| Input SPL | 0.4 - 6 V |
| Low pass filter | 50-12000 Hz |
| High pass filter | 50-12000 Hz |
| Crossover | 12 dB/Oct |
| Subsonic filter | 10-55 Hz |
| Input terminal | 4 Ga |
| Output terminal | 8 Ga |
| Damping factor | ≥ 180 |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ≥ 90 dB |
| Size (W×L×H) | 10.69 × 5.98 × 2.15 inch |
| Gross weight | 5.67 lb (2.57 kg) |
