Model | AHL-200.4 |
Class | D |
Number of the channels | 4 |
Frequency response | 10-20000 Hz |
2 Ohm RMS Power (14.4 V) | 330 W x 4 |
4 Ohm RMS Power (14.4 V) | 200 W x 4 |
4 Ohm RMS Power (Bridge) | 710 W x 2 |
Minimum permissible load on the channel | 2 Ohm |
Minimum permissible load in a bridge connection | 4 Ohm |
Low pass filter | 30 -8000 Hz |
High pass filter | 10-8000 Hz |
LPF and HPF simultaneous operation | True |
Crossover | 12 dB/Oct |
Input terminal | 0 Ga |
Output terminal | 8 Ga |
Damping factor | ≥ 100 |
Working voltage | 9 - 15 V |
Signal-to-noise ratio | ≥ 90 dB |
Size (W×L×H) | 14.96 × 6.85 × 2.17 inch |
Gross weight | 10.80 lb (4.90 kg) |
