Apocalypse AAB-1800.2D

Series: Apocalypse


Specifications

ModelAAB-1800.2D
ClassD
Number of the channels2
Frequency response15-20000 Hz
1 Ohm RMS Power (14.4 V)1800 W x 2
2 Ohm RMS Power (14.4 V)1020 W x 2
4 Ohm RMS Power (14.4 V)670 W x 2
2 Ohm RMS Power (Bridge)3600 W x 1
4 Ohm RMS Power (Bridge)2020 W x 1
Minimum permissible load on the channel1 Ohm
Minimum permissible load in a bridge connection2 Ohm
Input SPL0.2 - 6 V
Low pass filter50-20000 Hz
High pass filter15-1000 Hz
LPF and HPF simultaneous operationTrue
Crossover12 dB/Oct
Bass frequency adjustment0-12 Hz
Input terminal0 Ga
Output terminal8 Ga
Damping factor≥ 260
Working voltage9 - 15 V
Signal-to-noise ratio≥ 100 dB
Size (W×L×H)9.72 × 11.10 × 2.93 inch
Gross weight2.20 lb (1.00 kg)
