Model | AAB-1800.2D |
Class | D |
Number of the channels | 2 |
Frequency response | 15-20000 Hz |
1 Ohm RMS Power (14.4 V) | 1800 W x 2 |
2 Ohm RMS Power (14.4 V) | 1020 W x 2 |
4 Ohm RMS Power (14.4 V) | 670 W x 2 |
2 Ohm RMS Power (Bridge) | 3600 W x 1 |
4 Ohm RMS Power (Bridge) | 2020 W x 1 |
Minimum permissible load on the channel | 1 Ohm |
Minimum permissible load in a bridge connection | 2 Ohm |
Input SPL | 0.2 - 6 V |
Low pass filter | 50-20000 Hz |
High pass filter | 15-1000 Hz |
LPF and HPF simultaneous operation | True |
Crossover | 12 dB/Oct |
Bass frequency adjustment | 0-12 Hz |
Input terminal | 0 Ga |
Output terminal | 8 Ga |
Damping factor | ≥ 260 |
Working voltage | 9 - 15 V |
Signal-to-noise ratio | ≥ 100 dB |
Size (W×L×H) | 9.72 × 11.10 × 2.93 inch |
Gross weight | 2.20 lb (1.00 kg) |
