Apocalypse AAB-12900.1D

Series: Apocalypse


Specifications

ModelAAB-12900.1D
ClassD
Number of the channels1
Frequency response10-20000 Hz
1 Ohm RMS Power (14.4 V)13000 W
1 Ohm RMS Power (12 V)11000 W
2 Ohm RMS Power (14.4 V)7500 W
4 Ohm RMS Power (14.4 V)4500 W
Minimum permissible load on the channel1 Ohm
Input SPL0.5 - 8 V
Low pass filter80-20000 Hz
High pass filter15-80 Hz
Crossover12 dB/Oct
Bass frequency adjustment35-70 Hz
Input terminal0 Ga
Output terminal8 Ga
Damping factor≥ 210
Working voltage9 - 15 V
Signal-to-noise ratio≥ 100 dB
Size (WxLxH)20.83 x 9.72 x 2.89 inch
Gross weight23.15 lb (10.50 kg)
